1、Technical quality assurance.
2、Shell cold rolled plate high temperature baking paint.
3、High temperature protection, current cut off, multiple safety protection, use more assured.
4、840 stainless steel electric heating tube, more durable.
5、Fast heat generation, fast heat dissipation, fast temperature rise.
6、Intelligent temperature control, more convenient to use.
7、Adjust arbitrarily within the temperature and time range.
Model | Power (kw) | Room(M3)* | Voltage(AC V) | Current(A) | Specifications for power wire | Product size/mm | packaging size |
SAT-35-2V | 3kw | 2-3 | 200-240V(1PH/2PH) | 15 | 11AWG or 4.0mm2 | 400*215*490 | 450*265*530 |
SAT -45 | 4.5kw | 3-6 | 200-240V(1PH/2PH) | 21 | 10AWG or 4.0mm2 | 330*300*520 | 450*325*530 |
208V/3PH | 13 | 11AWG or 2.5mm2 | |||||
380-415V/3PH | 7 | 14AWG or 1.5mm2 | |||||
SAT-60 | 6kw | 5-7 | 200-240V(1PH/2PH) | 28 | 9AWG or 6.0mm2 | ||
208V/3PH | 17 | 11AWG or 4.0mm2 | |||||
380-415V/3PH | 9 | 13AWG or 2.5mm2 | |||||
SAT-75 | 7.5kw | 6-8 | 200-240V(1PH/2PH) | 34 | 8AWG or 6.0mm2 | ||
208V/3PH | 20 | 10AWG or 4mm2 | |||||
380-415V/3PH | 11 | 12AWG or 2.5mm2 | |||||
SAT-90 | 9kw | 8-11 | 200-240V(1PH/2PH) | 41 | 7AWG or 10.0mm2 | ||
208V/3PH | 25 | 9AWG or 6.0mm2 | |||||
380-415V/3PH | 14 | 12AWG or 2.5mm2 |
